Figure 5-2 Dual CPU Variant

xlink = 172.27.1.10
ETH1 = 172.26.1.10
bcm = not configured by default
5.2.1.2

Firmware Upgrade

5.2.1.2.1 BMC Upgrade

The BMC can be upgraded using ipmitool over LAN as shown below:
NOTE: BMC default front panel Ethernet IP address is 192.168.201.9
1. Set your IP address on CPU1 or external server, to the same subnet as BMC.
(192.168.201.xxx)
2. Download hpm.1 image to CPU1 or external server and execute the following
command:
ipmitool –I lanplus –H 192.168.201.9 –z 0x7fff –U admin –P admin hpm
upgrade <image name>
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
ETH1
Front
Panel
CPU 1
bcm interface
xlink interface
bcm = not configured by default
Broadcom Switch
Software Configuration
ETH2
Front
Panel
CPU 2
xlink = DHCP
ETH2 = 172.26.1.20
bcm interface
