Table 1-9
Pin Function
A47 PERp7 - Lane 7 from Card to CPU1
A48 PERn7 - Lane 7 from Card to CPU1
A49 Ground
A50 NC
A51 Ground
A52 PERp8 - Lane 0 from Card to CPU2
A53 PERn8 - Lane 0 from Card to CPU2
A54 Ground
A55 Ground
A56 PERp9 - Lane 1 from Card to CPU2
A57 PERn9 - Lane 1 from Card to CPU2
A58 Ground
A59 Ground
A60 PERp10 - Lane 2 from Card to CPU2
A61 PERn10 - Lane 2 from Card to CPU2
A62 Ground
A63 Ground
A64 PERp11 - Lane 3 from Card to CPU2
A65 PERn11 - Lane 3 from Card to CPU2
A66 Ground
A67 Ground
A68 PERp12 - Lane 4 from Card to CPU2
A69 PERn12 - Lane 4 from Card to CPU2
A70 Ground
A71 Ground
A72 PERp13 - Lane 5 from Card to CPU2
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
PCIe Slot Connector Pinout (continued)
System Overview
Pin Function
B47 Ground
B48 PRSNT2# - Card Presence Detect
B49 Ground
B50 PETp8 - Lane 0 from CPU2 to Card
B51 PETn8 - Lane 0 from CPU2 to Card
B52 Ground
B53 Ground
B54 PETp9 - Lane 1 from CPU2 to Card
B55 PETn9 - Lane 1 from CPU2 to Card
B56 Ground
B57 Ground
B58 PETp10 - Lane 2 from CPU2 to Card
B59 PETn10 - Lane 2 from CPU2 to Card
B60 Ground
B61 Ground
B62 PETp11 - Lane 3 from CPU2 to Card
B63 PETn11 - Lane 3 from CPU2 to Card
B64 Ground
B65 Ground
B66 PETp12 - Lane 4 from CPU2 to Card
B67 PETn12 - Lane 4 from CPU2 to Card
B68 Ground
B69 Ground
B70 PETp13 - Lane 5 from CPU2 to Card
B71 PETn13 - Lane 5 from CPU2 to Card
B72 Ground
