FRU Installation
The Extreme Edge Server is designed for side-to-side airflow. The PCIe
card needs to be designed similarly. PCIe boards designed for the
traditional airflow direction may cause overheating of the PCIe card or
Extreme Edge Server.
3.3

SFP/SFP+ Modules

The five SFP+ ports on the front panel can accept SFP+ (10G) or SFP (1G) modules.
Limited testing has been done with 10GBase-SR and 10GBase-LR optical modules as well
as direct-attach copper cables. High powered optics may need to be rated to industrial
temperatures. The following is a list of modules that have been verified to work in limited
testing, but most other commercially available modules should work as well.

Molex 74752-1051 (SFP+, direct attach copper, 0.5m)
 Molex 74752-2301 (SFP+, direct attach copper, 3m)
 Tyco 2032237-6 (SFP+, direct attach copper, 5m)
 Broadcom/Avago ABCU-5700RZ (SFP, 1000Base-T)
 Finisar FTLX1471D3BCL (SFP+, 10GBase-LR)
 Finisar FTLX1471D3BCV (SFP+, dual-rate 1G/10GBase-SR)
 Finisar FTLX8571D3BCL (SFP+, 10GBase-SR)
Refer to the documentation for your specific SFP+ module for installation instructions.
