Table 1-16
Pin
51
53
55
57
59
61
63
65
67
69
71
73
75
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
NVMe Module Pinout (continued)
Function
GND
100MHz Refclk-
100MHz Refclk+
GND
Key
Key
Key
Key
nc
nc
GND
GND
GND
Pin Function
52 nc
54 nc
56 nc
58 nc
60 Key
62 Key
64 Key
66 Key
68 Susclk
70 +3.3V
72 +3.3V
74 +3.3V
