System Overview
1.6.1

CPU SKU Support

Many different CPU SKUs are available, having various core counts, core frequencies,
cache sizes, and performance levels. On the Extreme Edge Server, the following SKU has
been qualified in the initial product release.
Table 1-2
CPU Type
Xeon D-1567
1.6.2

Memory Controller

The Broadwell-DE processor offers an Integrated Memory Controller (IMC) that has a
two-channel memory interface operating in the Independent Channel Mode. Each channel
consists of 64 data and 8 ECC bits, plus address, control, and management signals.
On the Extreme Edge Server, a DDR4 memory interface is supported. DDR mode is
determined by the DDR3_4_STRAP pin strapping. Signal DDR3_4_STRAP is pulled high
to select DDR4 mode.
Dual memory channels are supported with one DIMM per channel at up to 2166 MT/s.
Single and dual rank DIMMs are supported. Supported DRAM device densities are 4Gb
and 8Gb. Signaling voltage for the DDR4 interface is 1.2V.
The extended temperature-capable DIMMs are required for extended temperature
MC1600 Extreme Edge Server SKUs.
Possible DIMM types are shown in
type qualified for the initial product release is highlighted in green. These are x72 (ECC-
capable) modules.
Table 1-3
DIMM Type
RDIMM
RDIMM
RDIMM
RDIMM
54
CPU SKU Support
Cores Frequency
12 2.1GHz
ECC/Non-ECC DIMM Types
8Gb
Ranks
Chips
1 Rank x8 8GB
1 Rank x4 16GB
2 Rank x8 16GB
2 Rank x4 32GB
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
DDR4
Cache
Speed
18MB DDR4-2133
Table 1-3, they can be ECC or non-ECC modules. The
Qualified Module
X4B08QD8BNTDME-E-AY1 (C-temp)
X4B08QD8BNTDMW-E-AY1 (I-temp)
System Overview
SMART EC
TDP
Part #
65W 5106814F44
SMART EC
Part #
9706802B79
9706802B80
