Disconnect From The Power Feed; Removing The Server - SMART Embedded Computing MC1600 Installation And Use Manual

Do not disconnect DC power to shut down the server. This may lead to improper startup
behavior when powering up again.
DC Power-Down Procedure
To power down the DC system, proceed as follows:
1. Power down the server using a system management software.
2. Remove power from the server using the external disconnect.
3. Verify that the power LED of the Extreme Edge Server is off.
4.4.2

Disconnect from the Power Feed

If you want to remove the server from the rack or cabinet, you must disconnect it from the
power feed. Make sure that the power feeds you plan to remove are powered off and
cannot be switched on while removing the server.
4.4.3

Removing the Server

Short Circuit and Personal Injury
Make sure the power feeds are powered off and cannot be switched on while you are
working.
Make sure all power input lines are not energized. Use caution with the tools to
prevent a short circuit
To remove the server from a rack, proceed as follows:
1. Disconnect power input cables.
2. Disconnect all cables from the PCIe cards and from the I/O panel.
3. Remove the earth ground connection.
4. Loosen and remove the mounting screws.
5. Remove the system from the rack.
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
System Installation
95
