Software Configuration

5.1

Introduction

The MC1600 Extreme Edge Server comes with software and firmware preinstalled and
ready for use when the system powers up. Each of the two CPUs boot up with an Insyde
UEFI BIOS that is accessible via the CPU's serial port, refer to
on page 93
which includes SMART Embedded Computing's Basic Blade Services (BBS). System
management and monitoring is accomplished through the BMC and provides a standard
IPMI implementation as well as some custom OEM commands.
5.2

Installed Software

This chapter describes the installed software and firmware along with the tools for
managing and configuring the softwares using the on-board utilities.
The software that is installed on the system includes the Linux-based BBS with a utility to
perform some of the firmware upgrades, a utility to configure the Broadcom switch, and a
utility to query and configure the front panel SFP modules.There is also AMI MegaRac
based BMC firmware that provides system management functionality including firmware
upgrades and sensor monitoring, and a BIOS for each system CPU as the boot firmware.
The following sections provide additional details about the utilities provided.
5.2.1

Basic Blade Services (BBS)

The Linux/BBS is based on CentOS 7.5 and contains Linux-based utilities to upgrade
firmware.To login to the BBS use the default username: password - root:root.
5.2.1.1

Default Network Configuration

When the provided BBS/Linux boots up on the CPUs, there is a default network
configuration that is enabled as shown in the following tables.
Table 5-1
CPU Interface
ETH1
CPU1
ETH2
bcm
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
for further information. Each CPU is initially configured to boot a CentOS Linux
Single CPU Variant
Description
Front panel interface
Front panel interface
Network interface from CPU1 to the Broadcom switch Not configured
Chapter 5
Connect the Serial Console
Default IP
Address
172.26.1.10
Not configured
©
-
