System Overview
Table 1-9
Pin Function
A73 PERn13 - Lane 5 from Card to CPU2
A74 Ground
A75 Ground
A76 PERp14 - Lane 6 from Card to CPU2
A77 PERn14 - Lane 6 from Card to CPU2
A78 Ground
A79 Ground
A80 PERp15 - Lane 7 from Card to CPU2
A81 PERn15 - Lane 7 from Card to CPU2
A82 Ground
1.11.2

-48V Power Connector

The input power connector is Molex 42820-2213 (2806858A05). The pinout of each power
connector is as shown.
Table 1-10
Pin
1
2
68
PCIe Slot Connector Pinout (continued)
Input Power Connector Pinout
Function
-48V RTN (+ input)
-48V (- input)
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
Pin Function
B73 Ground
B74 PETp14 - Lane 6 from CPU2 to Card
B75 PETn14 - Lane 6 from CPU2 to Card
B76 Ground
B77 Ground
B78 PETp15 - Lane 7 from CPU2 to Card
B79 PETn15 - Lane 7 from CPU2 to Card
B80 Ground
B81 PRSNT2# - Card Presence Detect
B82 NC
