set_aggregated_temperature_sensor(MAX(aggtemp))
sleep 1second and repeat forever
exit:
set_aggregated_temperature_sensor(disable)
Table 5-9
Request Data
Response Data
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
Set Aggregated Temperature Sensor
1 0xae
Version
2
Write as 0
FRU Device ID
3 1: the PCIe card
Other values are reserved
Aggregated Temperature Level
0xFF: Aggregated Temperature Sensor disabled
Other values
[7]: invalid flag
4
0: temperature in [5:0] is valid
1: temperature in [5:0] is invalid
[6]: write as 0
[5:0] aggregated temperature level
1 Completion Code
2 0xae
Software Configuration
