Connectors

1.11.1

PCI Express Connector

The pinout of x16 PCI Express edge connector is as defined in the PCI Express Card
Electromechanical Specification Revision 3.0 with the exception that PCIe lanes [15:8] are
defined as a second PCIe link, lanes [7:0] respectively. On the base board, these are routed
to CPU2 as previously noted in this document.
Table 1-9
Pin Function
A1 PRSNT1# - Card Presence Detect
A2 12V Power
A3 12V Power
A4 Ground
A5 JTAG TCK - Input to Card
A6 JTAG TDI - Input to Card
A7 JTAG TDO - Output from Card
A8 JTAG TMS - Input to Card
A9 3.3V Power
A10 3.3V Power
A11 PERST# - Reset to Card
A12 Ground
A13 100MHz Refclk+
A14 100MHz Refclk-
A15 Ground
A16 PERp0 - Lane 0 from Card to CPU1
A17 PERn0 - Lane 0 from Card to CPU1
A18 Ground
A19 NC
A20 Ground
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
PCIe Slot Connector Pinout
System Overview
Pin Function
B1 12V Power
B2 12V Power
B3 12V Power
B4 Ground
B5 SMCLK
B6 SMDAT
B7 Ground
B8 3.3V Power
B9 JTAG TRST# - Input to Card
B10 3.3V Aux Power
B11 NC
B12 NC
B13 Ground
B14 PETp0 - Lane 0 from CPU1 to Card
B15 PETn0 - Lane 0 from CPU1 to Card
B16 Ground
B17 PRSNT2# - Card Presence Detect
B18 Ground
B19 PETp1 - Lane 1 from CPU1 to Card
B20 PETn1 - Lane 1 from CPU1 to Card
