System Installation
1. Insert the Extreme Edge Server in an IP55/IP65 19" outdoor cabinet or a standard 19"
rack.
When installing the system, you must allow for 50mm (2 inches) on each side of the
server for proper airflow.
2. Fasten the server to the rack via the integrated mounting flanges using two bolts or
screws (minimum 6mm / 0.24 inch in diameter) on the left side and two on the right side
of the server. Torque the 6mm bolts to 4.3 Nm (38 in-lbs.)
NOTES:There are also four M2.5 screw locations on the rear of the chassis for optional rear
mounting support. SMART EC highly recommends the use of these locations with
custom brackets for high vibration environments.
The Extreme Edge Server can also be placed on a table top.
4.3.1

Ground the Server

1. Connect the rack grounding cable to the M4 system ground threaded insert on the front
right side of the server.
2. Torque the ground screw to a maximum of 1.2 Nm (10.6 in-lbs). Use a grounding cable
of size 1.25 mm
3. Connect the system permanently to the earth ground of the building.
4.3.2

Connect to the Power Feed

Make sure that a suitable -40 to -57VDC power source is within reach of the system. Two
independent power feeds can be connected to the system.
3. Connect the power connector to the DC power supply and insert the connector into the
Extreme Edge Server.
4. Turn on the external feed power. The input power LED on the front panel turns green.
92
2
for the DC system.
1.Put on an ESD wrist strap and connect the strap to the server by attaching
the front ESD jack/ESD snap (if you are not in an ESD safe environment).
2.Make sure the external power feeds that you plan to attach are powered
off and cannot be switched on while you are working.
