System Overview
1.11.8

NVMe Module Connectors

Table 1-16
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
74
NVMe Module Pinout
Function
GND
GND
PERn3 - Output from Module
PERp3 - Output from Module
GND
PETn3 - Input to Module
PETp3 - Input to Module
GND
PERn2 - Output from Module
PERp2 - Output from Module
GND
PETn2 - Input to Module
PETp2 - Input to Module
GND
PERn1 - Output from Module
PERp1 - Output from Module
GND
PETn1 - Input to Module
PETp1 - Input to Module
GND
PERn0 - Output from Module
PERp0 - Output from Module
GND
PETn0 - Input to Module
PETp0 - Input to Module
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
Pin Function
2 +3.3V
4 +3.3V
6 nc
8 nc
10 Activity LED
12 +3.3V
14 +3.3V
16 +3.3V
18 +3.3V
20 nc
22 nc
24 nc
26 nc
28 nc
30 nc
32 nc
34 nc
36 nc
38 nc
40 SMB_CLK
42 SMB_DATA
44 ALERT#
46 nc
48 nc
50 PERST#
