Software Configuration
Table 5-5
Request Data
Response Data
112
Set FRU Instance Power State
1 0xae
Version
2
Write as 0
FRU Device ID
0: the CPU1 and / or CPU2
3
1: the PCIe card
Other values are reserved
Entity ID
4 0x03: Entity processor
0x90: Entity PCIe slot
Entity Instance Number
For Entity 0x03 processor:
5 0x60+x: CPU x on the FRU (FRU0 or FRU1). x starts from 0
For Entity 0x90 PCIe slot:
0x60: entire slot
[7:5] reserved
[4:0] Power State:
0: power down
1: power up
2: reset
6
For processor entities, a reset of the CPU is performed. For a PCIe-
slot entity, a reset performs the #PERST of the slot.
Note: It depends on the hardware architecture whether a certain
power state is supported. There might be states that are not
supported by the hardware.
1 Completion Code
2 0xae
