Software Configuration
Table 5-10
Request Data
Response Data

5.2.2.1.5 Fan Control

The chassis fans run in the autonomous mode or the manual control mode and are
configurable via the Set Fan Speed Control command. When the fans are in the
autonomous mode, the fan control speed is determined by the aggregated temperature
level and the selected fan speed profile.Since only one cooling domain (cooling zone) is
supported, one setting is applied to all operating fans. Note that at low temperatures the
system may turn off some or all fans.

5.2.2.1.6 FRU Present State

There are two versions of the Get FRU Present State command. As shown in
Get FRU Present State Version
number, Product ID, and the device revision. Such information may not be available if either
the FRU does not provide the information or the FRU is in such a state that it cannot provide
the information to the BMC. In either case, zeros are returned.
118
Get Aggregated Temperature Sensor
1 0xae
Version
2
Write as 0
FRU Device ID
3 1: the PCIe card
Other values are reserved
1 Completion Code
2 0xae
Aggregated Temperature Level
0xFF: Aggregated Temperature Sensor disabled
Other values
[7]: invalid flag
3
0: temperature in [5:0] is valid
1: temperature in [5:0] is invalid
[6]: write as 0
[5:0] aggregated temperature level
1, the command also returns the manufacturer's IANA
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
Software Configuration
Table 5-12
