System Overview
1.11.5

USB 2.0 Connector

Table 1-13
Pin
1
2
3
4
1.11.6

USB 3.0 Connectors

Table 1-14
Pin
1
2
3
4
5
6
7
8
9
1.11.7

DDR4 DIMM Connectors

Table 1-15
Pin
1
2
3
4
70
USB 2.0 Connector Pinout
Function
VBUS
D-
D+
GND
USB 3.0 Connector Pinout
Function
VBUS
D-
D+
GND
SS_RX-
SS_RX+
GND
SS_TX-
SS_TX+
DDR4 DIMM Pinout
Signal Pin
nc 73
GND 74
DQ4 75
GND 76
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
Signal Pin
VDDQ 145
CK0 146
CK0# 147
VDDQ 148
Signal Pin
nc 217
VREF 218
GND 219
DQ5 220
System Overview
Signal
VDDQ
CK1
CK1#
VDDQ
