 RTC: I

Reset Generator
1.12.2

BMC Subsystem Features

 Platform Power Management
–
–
 FRU Management
–
 External Connectivity
–

Platform Control and Status
–
–
–
–
–
 Private I
–
–
–
 Additional GPIO
–
–
 BMC Debug Options
–
–
–
 PCIe
–
MC1600 Extreme Edge Server Installation and Use (6806870A02B)
2
C RTC w/128Byte EEPROM, 64Bytes SRAM, UID
Enable/disable -48V to 12V payload power brick (via Glue CPLD)
Power up/down or reset individual CPUs (via CPU CPLD)
Provides platform FRU information
10/100/1000BaseT connectivity (RJ-45) for management access
PERST_N control for PCIe slot
Power button signal
Power LED (signifies -48V is present)
PwrGood LED (signifies payload power present and good)
BMC Status LED
2
C Buses
6x temperature sensors
2x voltage sensors
Real time clock
Fan control: 3x PWM out, 7x tachometer in with noise filter
Analog voltage sensing for critical voltages
8x debug LED (green), 1x heartbeat LED (red)
4x debug switch (DIP switch type)
Console output via 3-pin header, R-232
PCIe GEN1 x1 link (endpoint) to CPU1 (root)
