IC-KP-B7-V95
Appendix A
Send a Single readcommand to channel 3 as an implicit command:
Byte no.
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
Byte 9
Byte 10
Byte 11
A command confirmation appears in the input field:
Byte no.
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
Byte 9
Byte 10
Byte 11
76
Use
Command code
Channel/Toggle bit
Use
Command code
Channel/Toggle bit
Status
Reply counter
Contents Description
01h
Command SF (Single read read
only code)
06h
Channel = 3
Toggle bit = 0
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
Contents Description
01h
Command SF (Single read read
only code)
06h
Channel = 3
Toggle bit = 0
FFh
Processing command.
07h
For every IDENT telegram, the
value on the reply counter
increases by 1.
00h
00h
00h
00h
00h
00h
00h
00h
