IC-KP-B7-V95
Appendix B
Output instance 109d - 56 bytes
Bytes
0 - 11
12 - 23
24 - 35
36 - 47
48 - 55
Output instance 110d - 136 bytes
Bytes
0 - 31
32 - 63
64 - 95
96 - 127
128 - 135
Output instance 111d - 248 bytes
Bytes
0 - 59
60 - 119
120 - 179
180 - 239
240 - 299
Output instance 112d - 0 bytes
Bytes
NONE
Class, instance, attribute
64h, 01d, 02h
64h, 02d, 02h
64h, 03d, 02h
64h, 04d, 02h
64h, 05d, 01h
Class, instance, attribute
64h, 01d, 03h
64h, 02d, 03h
64h, 03d, 03h
64h, 04d, 03h
64h, 05d, 01h
Class, instance, attribute
64h, 01d, 04h
64h, 02d, 04h
64h, 03d, 04h
64h, 04d, 04h
64h, 05d, 01h
Class, instance, attribute
N/A
Description
Channel 1 [12]
Channel 2 [12]
Channel 3 [12]
Channel 4 [12]
IDENT Control
Description
Channel 1 [32]
Channel 2 [32]
Channel 3 [32]
Channel 4 [32]
IDENT Control
Description
Channel 1 [60]
Channel 2 [60]
Channel 3 [60]
Channel 4 [60]
IDENT Control
Description
Heartbeat
91
