IC-KP-B7-V95
Commands
Enhanced buffered write read only code (EX):
Byte
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
Response:
Byte
Byte 0
Byte 1
Byte 2
Byte 3
The R/W head constantly attempts to write a read only code. After each
successful write, the response is sent and the system waits until a new tag is
within the detection range. The command then starts again from the beginning.
IPC11:
IDC-...-1K:
1. The first 3 bytes are hexadecimal (0h ... Fh), the last 4 bytes are decimal
(0d ... 9d).
Contents
Command code (24h)
FixLen/Channel/Toggle bit
FixType
FixType
Data 00h ... FFh
Data 00h ... FFh
Data 00h ... FFh
Data 00h ... FFh
Data 00h ... FFh
Contents
Command code (24h)
FixLen/Channel/Toggle bit
Status
Reply counter
<FixLen> = 5
<FixType> = '02' ASCII (30h 32h), the read only code cannot be
changed
'11' ASCII (31h 31h), the read only code can be
overwritten
<FixLen> =
7
<FixType> = '52' ASCII (35h 32h), the read only code can be
overwritten
Bit no.
7 6 5 4
0 0 1 0
<FixLen>
<FixType> (high byte)
<FixType> (low byte)
<Data>
<Data>
<Data>
<Data>
<Data>
Bit no.
7 6 5 4
0 0 1 0
0 1 0 1
<Status>
<ReplyCounter>
1
3 2 1 0
0 1 0 0
<Channel> <T>
3 2 1 0
0 1 0 0
<Channel> <T>
