Hardware Preparation and Installation
2.1
Overview
This chapter provides startup and safety instructions related to this product, hardware
preparation instruction that includes default switch settings. System considerations and
installation instructions for the baseboard, PMC, and transition module are also described
in this chapter.
A fully implemented MVME7100ET consists of the baseboard plus:
Two single-wide or one double-wide PCI Mezzanine Card (PMC) slot for added
versatility.
One transition module for support of the mapped I/O from the MVME7100ET
baseboard to the P2 connector.
Up to two optional XMCspan cards.
The following table lists the tasks that you are required to do before you can use this board.
Read this entire chapter, including all Caution and Warning notes, before you begin.
Table 2-1
Task
Unpack the hardware
Configure the hardware by setting
jumpers on the board and RTM
Install the MVME7216E transition module
in the chassis
Install PMC module (if required)
Install XMCspan module (if required)
Install the MVME7100ET in the chassis
Attach cabling and apply power
Install PIM on transition module (if
required)
Ensure that the firmware initializes the
MVME7100
Initialize the board
Examine and/or change environmental
parameters
Program the board as needed for your
applications
MVME7100ET Single Board Computer Installation and Use (6806800K87G)
Startup Overview
Page
Unpacking and Inspecting the Board on page 30
Configuring the Board on page 35
Address Switch, S1 on page 81
Transition Module on page 79
Installing Accessories on page 40
XMCspan Installation and Use (6806800H03)
Installing and Removing the Board on page 44
Completing the Installation on page 45
PMC Input/Output Module on page 83
MOTLoad Firmware on page 85
MOTLoad Firmware on page 85
MVME7100ET Single Board Computer Programmer's
Reference
MVME7100ET Single Board Computer Programmer's
Reference
Chapter 2
SEEPROM
and
29
