Table 6-1
Command
testSeriallntLoop
testStatus
testSuite
testSuiteMake
testWatchdogTimer
tftpGet
tftpPut
time
transparentMode
tsShow
upLoad
version
vmeCfg
vpdDisplay
vpdEdit
wait
waitProbe
6.4

Using the Command Line Interface

Interaction with MOTLoad is performed via a command line interface through a serial port
on the single board computer, which is connected to a terminal or terminal emulator (for
example, Window's Hypercomm). The default MOTLoad serial port settings are: 9600
baud, 8 bits, no parity.
The MOTLoad command line interface is similar to a UNIX command line shell interface.
Commands are initiated by entering a valid MOTLoad command (a text string) at the
MOTLoad command line prompt and pressing the carriage-return key to signify the end of
input. MOTLoad then performs the specified action. An example of a MOTLoad command
line prompt is shown below. The MOTLoad prompt changes according to what product it is
used on (for example, MVME6100, MVME3100, MVME7100).
Example:
MVME7100>
MVME7100ET Single Board Computer Installation and Use (6806800K87G)
MOTLoad Commands (continued)
Description
Serial Internal Loopback
Display the Contents of the Test Status Table
Execute Test Suite
Make (Create) Test Suite
Tests the Accuracy of the Watchdog Timer Device
TFTP Get
TFTP Put
Display Date and Time
Transparent Mode (Connect to Host)
Display Task Status
Up Load Binary Data from Target
Display Version String(s)
Manages user specified VME configuration parameters
VPD Display
VPD Edit
Wait for Test Completion
Wait for I/O Probe to Complete
MOTLoad Firmware
