6.5.6

Restoring Default VME Settings

To restore all of the changeable VME setting back to their default settings, type the
following at the firmware prompt:
vmeCfg –z
6.6

Remote Start

As described in the MOTLoad Firmware Package User's Manual, listed in
Related Documentation, remote start allows the user to obtain information about the target
board, download code and/or data, modify memory on the target, and execute a
downloaded program. These transactions occur across the VMEbus in the case of the
MVME7100ET. MOTLoad uses one of four mailboxes in the Tsi148 VME controller as the
inter-board communication address (IBCA) between the host and the target.
CR/CSR slave addresses configured by MOTLoad are assigned according to the
installation slot in the backplane, as indicated by the VME64 Specification. For reference,
the following values are provided:
CS/CSR Starting Address
1
2
3
4
5
6
7
8
9
A
B
C
For further details on CR/CSR space, please refer to the VME64 Specification, listed in
Appendix B, Related
MVME7100ET Single Board Computer Installation and Use (6806800K87G)
Slot Position
0x0008.0000
0x0010.0000
0x0018.0000
0x0020.0000
0x0028.0000
0x0030.0000
0x0038.0000
0x0040.0000
0x0048.0000
0x0050.0000
0x0058.0000
0x0060.0000
Documentation.
MOTLoad Firmware
Appendix B,
