Pci Mezzanine Card (Pmc) Connectors (J11-J14, J21-J23); Table 3-5 Pmc Slot 1 Connector (J11) Pin Assignments - SMART Embedded Computing MVME7100ET Installation And Use Manual

Table 3-4
Pin #
4
5
6
7
8
3.3.3.3

PCI Mezzanine Card (PMC) Connectors (J11-J14, J21-J23)

There are seven 64-pin SMT connectors on the MVME7100ET to provide 32/64-bit PCI
interfaces and P2 I/O for one optional add-on PMC.
PMC slot connector J14 contains the signals that go to VME P2 I/O rows A, C, D, and Z.
The pin assignments for these connectors are as follows:
Table 3-5
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
MVME7100ET Single Board Computer Installation and Use (6806800K87G)
Ethernet Connectors (J4A/J4B) Pin Assignments (continued)
10/100/1000 Mb/s
_DC+
_DC-
_DB-
_DD+
_DD-
PMC Slot 1 Connector (J11) Pin Assignments
Signal
TCK
GND
INTB#
PMCPRSNT1#
INTD#
GND
CLK
GND
PMCREQ1#
+3.3V (VIO)
AD28
AD25
GND
AD22
AD19
+3.3V (VIO)
FRAME#
Controls, LEDs, and Connectors
Signal
-12V
INTA#
INTC#
+5V
PCI_RSVD
+3.3Vaux
GND
PMCGNT1#
+5V
AD31
AD27
GND
C/BE3#
AD21
+5V
AD17
GND
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
53
