Damage of Circuits
Electrostatic discharge and incorrect installation and removal can damage circuits
or shorten their life.
Before touching the board or electronic components, make sure that you are
working in an ESD-safe environment.
Product Damage
Only use injector handles for board insertion to avoid damage to the front panel
and/or PCB. Deformation of the front panel can cause an electrical short or other
board malfunction.
Board Malfunction
Switches marked as "reserved" might carry production-related functions and can
cause the board to malfunction if their setting is changed.
Do not change settings of switches marked as "reserved". The setting of switches
which are not marked as "reserved" has to be checked and changed before board
installation.
Installation and Removal Procedure
To begin the installation of the transition module in a chassis, proceed as follows:
1. Turn all equipment power OFF and disconnect the power cable from the AC power
source.
2. Remove the chassis cover as instructed in the equipment user's manual.
3. Remove the filler panel(s) from the appropriate card slot(s) at the rear of the chassis (if
the chassis has a rear card cage).
4. Install the top and bottom edge of the transition module into the rear guides of the
chassis.
5. Ensure that the levers of the two injector/ejectors are in the outward position.
6. Slide the transition module into the chassis until resistance is felt.
7. Simultaneously move the injector/ejector levers in an inward direction.
8. Verify that the transition module is properly seated and secure it to the chassis using
the two screws located adjacent to the injector/ejector levers.
9. Connect the appropriate cables to the transition module.
To remove the transition module from the chassis, reverse the procedure and press the red
locking tabs (IEEE handles only) to extract the board.
