Table 3-6 Pmc Slot 1 Connector (J12) Pin Assignments - SMART Embedded Computing MVME7100ET Installation And Use Manual

Controls, LEDs, and Connectors
Table 3-5
Pin
35
37
39
41
43
45
47
49
51
53
55
57
59
61
63
Table 3-6
Pin
1
3
5
7
9
11
13
15
17
19
21
54
PMC Slot 1 Connector (J11) Pin Assignments (continued)
Signal
GND
DEVSEL#
GND
PCI_RSVD
PAR
+3.3V (VIO)
AD12
AD09
GND
AD06
AD04
+3.3V (VIO)
AD02
AD00
GND
PMC Slot 1 Connector (J12) Pin Assignments
Signal
+12V
TMS
TDI
GND
Not Used
Pull-up
RST#
+3.3V
Not Used
AD30
GND
MVME7100ET Single Board Computer Installation and Use (6806800K87G)
Controls, LEDs, and Connectors
Signal
IRDY#
+5V
LOCK#
PCI_RSVD
GND
AD15
AD11
+5V
C/BE0#
AD05
GND
AD03
AD01
+5V
REQ64#
Signal
TRST#
TDO
GND
Not Used
Not Used
+3.3V
Pull-down
Pull-down
GND
AD29
AD26
Pin
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
Pin
2
4
6
8
10
12
14
16
18
20
22
