Controls, LEDs, and Connectors
Table 3-8
Pin
57
59
61
63
Table 3-9
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
58
PMC Slot 1 Connector (J14) Pin Assignments (continued)
Signal
PMC1_57 (P2-C29)
PMC1_59 (P2-C30)
PMC1_61 (P2-C31)
PMC1_63 (P2-C32)
PMC Slot 2 Connector (J21) Pin Assignments
Signal
TCK
GND
INTD#
PMCPRSNT1#
INTB#
GND
CLK
GND
PMCREQ1#
+3.3V (VIO)
AD28
AD25
GND
AD22
AD19
+3.3V (VIO)
FRAME#
GND
DEVSEL#
GND
PCI_RSVD
PAR
MVME7100ET Single Board Computer Installation and Use (6806800K87G)
Controls, LEDs, and Connectors
Signal
PMC1_58 (P2-A29)
PMC1_60 (P2-A30)
PMC1_62 (P2-A31)
PMC1_64 (P2-A32)
Signal
-12V
INTC#
INTA#
+5V
PCI_RSVD
+3.3Vaux
GND
PMCGNT1#
+5V
AD31
AD27
GND
C/BE3#
AD21
+5V
AD17
GND
IRDY#
+5V
LOCK#
PCI_RSVD
GND
Pin
58
60
62
64
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
