Introduction
Table 1-1
Function
PCI_E
I/O
Ethernet
Serial Interface
Timers
Watchdog Timer
VME Interface
Form Factor
26
Features List (continued)
Features
8X Port to XMC Expansion
8X Port to 5 Port PCI Express switch
One front panel mini DB-9 connector for front I/O: one serial
channel
Two front panel RJ-45 connectors with integrated LEDs for front
I/O: two 10/100/1000 Ethernet channels
PMC site 1 front I/O and rear P2 I/O
PMC site 2 front I/O
Four 10/100/1000 MC864xD Ethernet channels: two front panel
Ethernet connectors and two channels for rear P2 I/O
One 16550-compatible, 9.6 to 115.2 Kbaud, MC864xD,
asynchronous serial channel: one channel for front panel I/O
One quad UART (QUART) controller to provide four 16550-
compatible, 9.6 to 115.2 Kbaud, asynchronous serial channels: four
channels for rear P2 I/O
Four 32-bit MC864xD timers
Four 32-bit timers in a PLD
One watchdog timer in PLD
VME64 (ANSI/VITA 1-1994) compliant (3 row backplane 96-pin
VME connector)
VME64 Extensions (ANSI/VITA 1.1-1997) compliant (5 row
backplane 160-pin VME connector)
2eSST (ANSI/VITA 1.5-2003) compliant
Two five-row P1 and P2 backplane connectors
One Tsi148 VMEbus controller
Standard 6U VME, one slot
