Controls, LEDs, and Connectors
Table 3-12
Pin
3
4
5
6
7
8
9
3.3.3.5

VMEbus P1 Connector

The VME P1 connector is a 160-pin DIN. The P1 connector provides power and VME
signals for 24-bit address and 16-bit data. The pin assignments for the P1 connector is as
follows:

Table 3-13 VMEbus P1 Connector Pin Assignments

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
62
COM1 Port Connector Pin Assignments (continued)
ROW Z ROW A
Reserved D00
GND D01
Reserved D02
GND D03
Reserved D04
GND D05
Reserved D06
GND D07
Reserved GND
GND SYSCLK
Reserved GND
GND DS1*
Reserved DS0*
GND WRITE*
Reserved GND
GND DTACK*
MVME7100ET Single Board Computer Installation and Use (6806800K87G)
Signal
TX
No Connect
GND
No Connect
RTS
CTS
No Connect
ROW B ROW C
BBSY* D08
BCLR* D09
ACFAIL* D10
BG0IN* D11
BG0OUT* D12
BG1IN* D13
BG1OUT* D14
BG2IN* D15
BG2OUT* GND
BG3IN* SYSFAIL*
BG3OUT* BERR*
BR0* SYSRESET*
BR1* LWORD*
BR2* AM5
BR3* A23
AM0 A22
Controls, LEDs, and Connectors
ROW D
+5V 1
GND 2
Reserved 3
Reserved 4
Reserved 5
Reserved 6
Reserved 7
Reserved 8
GAP_L 9
GA0_L 10
GA1_L 11
Reserved 12
GA2_L 13
Reserved 14
GA3_L 15
Reserved 16
