Controls, LEDs, and Connectors

3.1

Overview

This chapter summarizes the controls, LEDs, connectors, and headers for the
MVME7100ET baseboard. Connectors for the MVME721ET transition module can be
found in Rear Panel Connectors on page
3.2

Board Layout

The following figure shows the components, LEDs, connectors, and the reset switch on the
MVME7100ET.

Figure 3-1 Component Layout

Battery
J3
J2
J4A/J4B
MVME7100ET Single Board Computer Installation and Use (6806800K87G)
82.
J21 J22
S1 S2
Chapter 3
P1
J23
J11
J12
J13
J14
P2
Heat Sink
47
