Introduction

1.1

Features

The MVME7100ET Single Board Computeris a VMEbus board based on the MC8640D and
MC8641D integrated PowerPC processors. It is a full 6U board and occupies a single VME
card slot with PMC cards installed. The MVME7100ET is compliant with the VITA standards
VMEbus, 2eSST, and PCI-X as listed in
Table 1-1
Function
Processor / Host Controller /
Memory Controller
System Memory
2
I C
NOR Flash
NAND Flash
NVRAM
MVME7100ET Single Board Computer Installation and Use (6806800K87G)
Features List
Features
One MC864xD Integrated Processor
Two e600 cores with integrated L2
Core frequency of 1.067 or 1.33GHz
One integrated four channel DMA controller
Two integrated PCIE interfaces
Four integrated 10/100/1000 Ethernet controllers
One integrated DUART
Two integrated I
One integrated Programmable Interrupt Controller
One integrated Local Bus Controller
Two integrated DDR2 SDRAM controllers
Two banks of DDR2 SDRAM with ECC
2GB or 4GB
One 8KB VPD serial EEPROM
Two 64KB user configuration serial EEPROMs
One Real Time Clock (RTC) with removable battery
Dual temperature sensor
Two SPDs for memory
Connection to XMCspan and rear transition module
128MB soldered flash with two alternate 1 MB boot sectors
selectable via hardware switch
H/W switch or S/W bit write protection for entire logical bank
Up to two devices available:
4GB - 1 device
8GB - 2 device
One 512KB MRAM extended temperature range
Two 64KB serial EEPROMs
Appendix B, Related Documentation on page
2
C controllers
Chapter 1
109.
