Chapter 4
Functional Description
4.1
Overview
The MVME7100ET VMEbus board is based on the MC8640D (1.067GHz versions) and the
MC8641D (1.33GHz versions) Integrated Processors. The MVME7100ET provides front
panel access to one serial port with a mini DB-9 connector and two 10/100/1000 Ethernet
ports with two RJ-45 connectors. The front panel includes a fail indicator LED, user-defined
indicator LED, and a reset/abort switch.
The MVME721ET transition module provides rear panel access to four serial ports with one
RJ-45 connector per port and two 10/100/1000 Ethernet ports with two RJ-45 connectors.
The transition module also provides two planar connectors for one PIM with front I/O.
The block diagram for the MVME7100ET Single Board Computer is shown in
Table 4-1
and
the block diagram for the MVME721ET transition module is shown in
Figure
5-2.
MVME7100ET Single Board Computer Installation and Use (6806800K87G)
69
