Transition Module

5.1

Overview

This chapter provides information on the MVME721ET transition module's features. It also
includes a drawing of the module showing the components and rear panel connectors.
5.2

Transition Module Layout

The following illustration shows the component layout and connectors on the MVME721ET
transition module.

Figure 5-1 Component Layout

C1
U1
L1
C39
MVME7100ET Single Board Computer Installation and Use (6806800K87G)
T2
T1
C25
U4
C38
L2
J10
C38
S1
P2
U2
J14
J1
J2
S1 SMT Switch
