Headers; Processor Cop Header (P4); Table 3-16 Processor Cop Header (P4) Pin Assignments - SMART Embedded Computing MVME7100ET Installation And Use Manual

Controls, LEDs, and Connectors
Table 3-15
Pin
49
51
53
55
57
59
61
63
3.4

Headers

This section describes the pin assignments of the Headers on the MVME7100ET.
3.4.1

Processor COP Header (P4)

There is one standard 16-pin header that provides access to the COP function. The pin
assignments for this header are as follows:
Table 3-16
Pin
1
3
5
7
9
11
13
15
NOTE: Pin 6 +3.3V has a 100W resistor to +3.3V.
66
MVME721ET Host I/O Connector (J10) Pin Assignments (continued)
Signal
No Connect
No Connect
+5V
No Connect
No Connect
No Connect
No Connect
No Connect
Processor COP Header (P4) Pin Assignments
Signal
CPU_TDO
CPU_TDI
Pullup
CPU_TCK
CPU_TMS
CPU_SRST_L
CPU_HRST_L
CPU_CKSTPO_L
MVME7100ET Single Board Computer Installation and Use (6806800K87G)
Controls, LEDs, and Connectors
Signal
GND
No Connect
No Connect
No Connect
+3.3V
No Connect
No Connect
No Connect
Signal
No Connect
CPU_TRST_L
CPU_VIO (+3.3V)
CPU_CKSTPI_L
No Connect
GND
KEY (no pin)
GND
Pin
50
52
54
56
58
60
62
64
Pin
2
4
6
8
10
12
14
16
