Hardware Preparation and Installation

2.1

Environmental and Power Requirements

You must make sure that following environmental requirements meet when board is
operated in your system configuration.
Operating temperatures refer to the temperature of air circulation around the board,
but not the component temperature.
2.1.1

Environmental Requirements

The following table provides the environmental requirement details for the board.
Table 2-1
Environmental Factor
Temperature
Humidity
Vibration
Shock
Altitude
2.1.2

Power Requirements

This board is designed to operate with the input voltages and currents as defined in the fol-
lowing tables.
Table 2-2
memory)
State
G3 (AC off)
Idle (CMOS Setup)
COMX-CORE-2610-ET Installation and Use (6806800P11E)
Environmental Requirements for Module with CORE i7 2610UE
Operating
-20°C to 70°C
10% to 90% Non-condensing
0.01g ^2/Hz at 5-500 Hz
Random Vibration
-60m to 4000m ASL
Module with CORE i7 2610UE Power Requirement (with 2x2 GB non-ECC
+12V
0
1.11A
NOTICE
5VSB VCC_RTC
0 5uA
0.042A 0
Chapter 2
Non-operating
-40°C to 85°C
5% to 95% Non-condensing
20 G peak (half sine) 11 ms
Total power
consumption
0.015mW
13.53W
33
