Introduction

1.1

Overview

This chapter briefly describes the board level hardware features of the MVME4100 Single
Board Computer. Refer to the MPC8548E Reference Manual listed in
Documentation, for more detail and programming information.
At the time of publication of this manual, the MVME4100 is available in the configurations
shown below.
Table 1-1
Marketing Number
MVME4100-0171
MVME4100-0173
1.2

Features

Refer to the following table for a summary of the features common to all board variations.
Table 1-2
Function
Processor / Host Controller /
Memory Controller
System Memory
MVME4100 Single Board Computer Programmer's Reference (6806800H19D)
Board Variants
Processor
1.3GHz MPC8548E, 4GB NAND flash, 2GB DDR2, Scanbe handles
1.3GHz MPC8548E, 4GB NAND flash, 2GB DDR2, IEEE handles
Features List
Features
One MPC8548E Integrated Processor
One e500 core with integrated L2
Core frequency of 1.3 GHz
One integrated four channel DMA controller
One integrated PCI-E interface
One integrated PCI-X interface
Four integrated 10/100/1000 Ethernet controllers
One integrated DUART
Two integrated I
One integrated Programmable Interrupt Controller
One integrated Local Bus Controller
One integrated DDR2 SDRAM controller
One DDR2 SO-CDIMM for SDRAM with ECC
2 GBytes
Up to DDR533
2
C controllers
Chapter 1
Appendix B, Related
15
