3 How to Install
NOTE!
All cable lugs/shoes must mount within the width of the terminal bus bar.
3.3.3 Terminal locations - D enclosures
3
Take the following terminal positions into consideration when you design for cable access.
Figure 3.10: Position of power connections, D3/D4 enclosure
Figure 3.11: Position of power connections with disconnect switch, D1/D2 enclosure
3-14
MG.33.U2.22 - VLT
®
is a registered Danfoss trademark
VLT
®
Automation Drive FC 300
Instruction Manual High Power
