Danfoss VLT Automation Drive FC 300 Instruction Manual page 128

6 Warnings and Alarms
Alarm Word Extended Status Word
Bit Hex
0 00000001
1 00000002
2 00000004
3 00000008
4 00000010
5 00000020
6 00000040
7 00000080
8 00000100
9 00000200
10 00000400
11 00000800
12 00001000
13 00002000
14 00004000
15 00008000
6
16 00010000
17 00020000
18 00040000
19 00080000
20 00100000
21 00200000
22 00400000
23 00800000
24 01000000
25 02000000
26 04000000
27 08000000
28 10000000
29 20000000
30 40000000
31 80000000
Table 6.3: Description of Alarm Word, Warning Word, and extended Status Word
The alarm words, warning words and extended status words can be read out via the serial bus or optional serial communication bus for diagnosis. See
also par. 16-90 - 16-94.
WARNING 1, 10 Volts low:
The 10 V voltage from terminal 50 on the control card is below 10 V.
Remove some of the load from terminal 50, as the 10 V supply is over-
loaded. Max. 15 mA or minimum 590 Ω.
WARNING/ALARM 2, Live zero error:
The signal on terminal 53 or 54 is less than 50% of the value set in par.
6-10, 6-12, 6-20 or 6-22, respectively.
WARNING/ALARM 3, No motor:
No motor has been connected to the output of the adjustable frequency
drive.
WARNING/ALARM 4, Line phase loss:
A phase is missing on the supply side, or the AC line voltage imbalance
is too high.
This message also appears in case of a fault in the input rectifier on the
adjustable frequency drive.
Check the supply voltage and supply currents to the adjustable frequency
drive.
6-4
Dec Alarm Word
1 Brake Check
2 Pwr. Card Temp
4 Ground Fault
8 Ctrl.Card Temp
16 Ctrl. Word TO
32 Overcurrent
64 Torque Limit
128 Motor Th Over
256 Motor ETR Over
512 Inverter Overld.
1024 DC Undervolt
2048 DC Overvolt
4096 Short Circuit
8192 Soft-charge fault
16384 Line ph. Loss
32768 AMA Not OK
65536 Live Zero Error
131072 Internal Fault
262144 Brake Overload
524288 U-phase Loss
1048576 V-phase Loss
2097152 W-phase Loss
4194304 Ser. com. bus fault
8388608 24 V Supply Low
16777216 Line Failure
33554432 1.8 V Supply Low
67108864 Brake Resistor
134217728 Brake IGBT
268435456 Option Change
536870912 Drive Initialized
1073741824 Safe Stop (A68)
2147483648 Mech. brake low
MG.33.U2.22 - VLT
Alarm Word 2 Warning Word
ServiceTrip, Read/ Brake Check
Write
ServiceTrip, (re- Pwr. Card Temp
served)
ServiceTrip, Type- Ground Fault
code/Sparepart
ServiceTrip, (re- Ctrl.Card Temp
served)
ServiceTrip, (re- Ctrl. Word TO
served)
Overcurrent
Torque Limit
Motor Th Over
Motor ETR Over
Inverter Overld.
DC Undervolt
DC Overvolt
DC Voltage Low
DC Voltage High
Line ph. Loss
No Motor
Live Zero Error
KTY error 10 V Low
Fans error Brake Overload
ECB error Brake Resistor
Brake IGBT
Speed Limit
Ser. com. bus fault
24 V Supply Low
Line Failure
Current Limit
Low Temp
Voltage Limit
Encoder loss
Output freq. lim.
PTC 1 Safe Stop Safe Stop (W68)
(A71)
Dangerous Failure Extended Status Word
(A72)
WARNING 5, DC link voltage high:
The intermediate circuit voltage (DC) is higher than the overvoltage limit
of the control system. The adjustable frequency drive is still active.
WARNING 6, DC link voltage low
The intermediate circuit voltage (DC) is below the undervoltage limit of
the control system. The adjustable frequency drive is still active.
WARNING/ALARM 7, DC overvoltage:
If the intermediate circuit voltage exceeds the limit, the ad-
justable frequency drive trips after a given period of time.
Possible corrections:
Connect a brake resistor
Extend the ramp time
Activate functions in par. 2-10
Increase par. 14-26
® is a registered Danfoss trademark
VLT ® Automation Drive FC 300
Instruction Manual High Power
Warning Extended
Word 2 Status Word
Ramping
AMA Running
Start CW/CCW
Slow-down
Catch Up
Feedback High
Feedback Low
Output Current High
Output Current Low
Output Freq High
Output Freq Low
Brake Check OK
Braking Max
Braking
Out of Speed Range
OVC Active
AC Brake
KTY Warn Password Timelock
Fans Warn Password Protection
ECB Warn
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
PTC 1 Safe Unused
Stop (W71)
Unused
