Danfoss VLT Automation Drive FC 300 Instruction Manual page 114

5 General Specifications
Relay outputs:
Programmable relay outputs
Relay 01 Terminal number
Max. terminal load (AC-1)
Max. terminal load (AC-15)
Max. terminal load (DC-1)
Max. terminal load (DC-13)
Relay 02 (FC 302 only) Terminal number
Max. terminal load (AC-1)
Max. terminal load (AC-15)
Max. terminal load (DC-1)
Max. terminal load (DC-13)
Max. terminal load (AC-1)
Max. terminal load (AC-15)
5
Max. terminal load (DC-1)
Max. terminal load (DC-13)
Min. terminal load on 1-3 (NC), 1-2 (NO), 4-6 (NC), 4-5 (NO)
Environment according to EN 60664-1
1) IEC 60947 part 4 and 5
The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV).
Cable lengths and cross-sections:
Max. motor cable length, shielded/armored
Max. motor cable length, unshielded/unarmored
Maximum cross-section to control terminals, flexible/rigid wire without cable end sleeves
Maximum cross-section to control terminals, flexible wire with cable end sleeves
Maximum cross-section to control terminals, flexible wire with cable end sleeves with collar
Minimum cross-section to control terminals
Control card performance:
Scan interval
Control characteristics:
Resolution of output frequency at 0-1000 Hz
Precise start/stop
Repeat accuracy of
System response time (terminals 18, 19, 27, 29, 32, 33)
Speed control range (open-loop)
Speed control range (closed-loop)
Speed accuracy (open-loop)
Speed accuracy (closed-loop), depending on resolution of feedback device
All control characteristics are based on a 4-pole asynchronous motor
Surroundings:
Enclosure
Vibration test
Max. relative humidity
Aggressive environment (IEC 60068-2-43
Ambient temperature 1)
1) For higher ambient temperature, see special conditions in the Design Guide.
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Temperature during storage/transport
Maximum altitude above sea level without derating
Derating for high altitude, see special conditions in the Design Guide.
EMC standards, Emission
5-4
1)
on 1-3 (NC), 1-2 (NO) (Resistive load)
1) (Inductive load @ cosφ 0.4)
1) on 1-2 (NO), 1-3 (NC) (Resistive load)
1) (Inductive load)
1)
on 4-5 (NO) (Resistive load)
1)
on 4-5 (NO) (Inductive load @ cosφ 0.4)
1)
on 4-5 (NO) (Resistive load)
1) on 4-5 (NO) (Inductive load)
1) on 4-6 (NC) (Resistive load)
1) on 4-6 (NC) (Inductive load @ cosφ 0.4)
1) on 4-6 (NC) (Resistive load)
1) on 4-6 (NC) (Inductive load)
(terminals 18, 19)
MG.33.U2.22 - VLT
overvoltage category III/pollution degree 2
IP 00/ Chassis, IP 21/ Type 1, IP 54/ Type 12
5%-95% (IEC 721-3-3; Class 3K3 (non-condensing) during operation
Max. 113°F [45°C] (24-hour average maximum 122°F [40°C])
-13°-+°149/°158°F [-25°–+65°/70°C]
EN 61800-3, EN 61000-6-3/4, EN 55011
® is a registered Danfoss trademark
VLT ® Automation Drive FC 300
Instruction Manual High Power
2
1-3 (break), 1-2 (make)
240 V AC, 2 A
240 V AC, 0.2 A
60 V DC, 1A
24 V DC, 0.1A
4-6 (break), 4-5 (make)
400 V AC, 2 A
240 V AC, 0.2 A
80 V DC, 2 A
24 V DC, 0.1A
240 V AC, 2 A
240 V AC, 0.2 A
50 V DC, 2 A
24 V DC, 0.1 A
24 V DC 10 mA, 24 V AC 20 mA
492 ft [150 m]
984 ft [300 m]
0.0023 in. 2 [1.5 mm 2 ]/16 AWG
0.0016 in. 2 [1 mm 2 ]/18 AWG
0.00078 in. 2 [0.5 mm 2 ]/20 AWG
0.0039 in. 2 [0.25 mm 2 ]/24 AWG
1 ms
+/- 0.003 Hz
≤± 0.1 msec
≤ 2 ms
1:100 of synchronous speed
1:1000 of synchronous speed
30–4000 rpm: error ±8 rpm
0–6000 rpm: error ±0.15 rpm
0.7 g
class H 5
2
32°F [0°C]
14°F [-10°C]
3280 ft [1000 m]
