How to Install
3.2.4 Terminal Locations - E Enclosures
Terminal Locations - E1
Take the following position of the terminals into consideration when designing the cable access.
492[19.4]
323[12.7]
B
195[7.7]
Illustration 3.17 IP21 (NEMA Type 1) and IP54 (NEMA Type 12) Enclosure Power Connection Positions
®
VLT
Automation Drive FC 300 Operating Instructions
0[0.0]
MG33U402 - Rev. 2013-12-16
3
3
23
