VLT ® Automation Drive FC 300
Instruction Manual High Power
Kit contents
- Input plate assembled
- Instruction sheet 175R5795
Cautions
- The adjustable frequency drive contains dangerous voltages when connected to AC line voltage. No disassembly should be
attempted with power applied.
- Electrical parts on the adjustable frequency drive may contain dangerous voltages even after line power has been discon-
nected. Wait a minimum of 15 minutes after disconnecting line power before touching any internal components to ensure
that capacitors have fully discharged.
- The input plates contain metal parts with sharp edges. Use hand protection when removing and reinstalling.
- E1 frame input plates are heavy (44-77 lbs [20-35 kg] depending on the configuration). It is recommended that the disconnect
switch be removed from the input plate for easier installation and then be reinstalled on the input plate after the input plate
has been installed on the drive.
NOTE!
For further information, please see the Instruction Sheet,

3.4.5 Installation of Line Power Shield for VLT Drives

This section is for the installation of a line power shield for the FC series adjustable frequency drive frames D1, D2 and E1. It is not possible to install this
in the IP00/ Chassis versions since they include a metal cover as standard. These shields satisfy VBG-4 requirements.
Ordering numbers:
Frames D1 and D2: 176F0799
Frame E1: 176F1851
Torque requirements
M6 - 35 in-lbs (4.0 N-M)
M8 - 85 in-lbs (9.8 N-M)
M10 - 170 in-lbs (19.6 N-M)
NOTE!
For further information, please see the Instruction Sheet,
-
-
175R5795
175R5923
MG.33.U2.22 - VLT ® is a registered Danfoss trademark
Modification Label
Disconnect handle template (units w/ line power disconnect)
3 How to Install
3
3-33
