Field-Replaceable Units

RJ-45
Pin
8
Field-Replaceable Units
The vEdge 5000 router is a stiff sheet-metal structure that houses the hardware components. Field-replaceable
units (FRUs) are hardware components that you can remove and replace at your site. Table 1 lists the FRUs
in the vEdge routers.
The power supply, PIMs, transceivers, and fan tray are hot-removable and hot-insertable. You can remove
and replace these components without powering off the router or disrupting router functions.
Table 86:
FRU
AC power supply
8-Port RJ-45 Copper Gigabit Ethernet NIM
4-Port 10-Gigabit Ethernet SFP+ NIM
8-Port Gigabit Ethernet SFP NIM
Gigabit Ethernet transceivers
10-Gigabit Ethernet transceivers
Fan tray

Power Supply and Cooling in Cisco vEdge 5000 Routers

The vEdge 5000 router ships with two AC power supplies installed. Read this article to learn more about the
AC power supply in the router as well as about the cooling system and airflow through the router chassis.
AC Power Supply in vEdge 5000 Router
The vEdge 5000 router ships with two AC power supplies installed. The second power supply is for redundancy
and load-balancing. If one of the AC power supplies fails due to device failure or input power line failure, a
single unit is sufficient to power the entire router.
Hardware Installation Guide for vEdge Routers
234
Signal DB9 Signal
Pin
CTS 7 RTS
Cisco FRU PID required for RMA
• VEDGE-5000-PWR=
• NIM-8-1GE-RJ45=
• NIM-4-10GE-SFPP=
• NIM-8-1GE-SFP=
• VIP-SFP-1GE-SX=
• VIP-SFP-1GE-LX=
• VIP-SFP-1GE-BASET=
• VIP-SFP+-10GE-SR=
• VIP-SFP+-10GE-LR=
• VEDGE-5000-FAN=
vEdge 5000 Router
Part ID as per "show hardware
inventory"
NCS2-IGM806B-VV1
NCS2-IXM407A-VV1
NCS2-ISM802A-VV1
