Front and Rear Panel Components

This article describes the components on the front and rear panels of the vEdge 100m router. See At a Glance
for the exact location of these components on the router.
Front Panel LEDs
The vEdge 100m router has five chassis status LEDs located on the front panel. Table 1 describes the LEDs
, their color and states, and the status they indicate.
Table 18:
LED
Power
Specification
MIMO, dipole swivel
10 Watts
SMA male
50 Ohms
Omnidirectional
698MHz to 960MHz and 1710MHz to 2700Mhz
F (–40°C to 85°C)
Length: 6.37 in. (16.19 cm)
Width: 0.9 in. (2.38 cm)
Depth: 0.63 in. (1.59 cm)
Noncondensing, 65°C, 95% RH
Color Status
Green/Red • Off: System is not on
• Green: System is healthy and operational
• Red: Power supply fault
