vEdge 100 Router

The vEdge 100 router delivers highly secure site-to-site data connectivity to small business and home offices
(SOHO). The vEdge 100 router is a fixed-port-configuration router with the following features:
• Five built-in 10/100/1000 Mbps Ethernet ports
• Power over Ethernet (PoE) source support on one Ethernet port
• Encryption and QoS support
• 100 Mbps forwarding throughput (inclusive of encryption)
• Secure identification chip for anti-counterfeit and secure authentication
• Integrated power supply
• Kensington security lock slot to physically lock down the router
• GPS input for geographical location
• Desktop mount, wall mount, or rack-mountable in a 19-inch rack
Chassis Views
Figure 1 and Figure 2 show the front and back panels of the vEdge 100 router, indicating the location of the
power interfaces, status indicators, and chassis identification labels.
Figure 1: Front Panel of the vEdge 100 Router
Figure 2: Back Panel of the vEdge 100 Router
