vEdge 100m Router

The vEdge 100m router delivers highly secure site-to-site data connectivity to small business and home offices
(SOHO). The vEdge 100m router is a fixed-port-configuration router with the following features:
• Built-in LTE modem with mini-SIM (or 2FF) card
• Two multiband swivel-mount dipole antennas
• Supports a 4G/3G/2G–capable modem to connect to cellular networks
• Five built-in 10/100/1000–Mbps Ethernet ports
• Power over Ethernet (PoE) source support on one Ethernet port
• Encryption and QoS support
• 100 Mbps forwarding throughput (inclusive of encryption)
• Secure identification chip for anticounterfeit and secure authentication
• Integrated power supply
• Kensington security lock slot to physically lock down the router
• GPS input for geographical location
• Desktop mount or wall mount
Chassis Views
Figure 1 and Figure 2 show the front and back panels of the vEdge 100m router, indicating the locations of
the power interfaces, status indicators, and chassis identification labels.
Figure 1: Front Panel of the vEdge 100m Router
