3-10 Chapter 3: Configuring the 2085sc-IF8u Using CCW
User's Manual Pub. 0300305-01 Rev. A
modules run with default configurations as specified in the PLC Interfaces. The
initial configuration assumes a default configuration of 4 mA to 20 mA and the
17 Hz filter using the Engineering Unit ×1 setup.

3.3.4 PLC Interfaces

The 2085 platform treats all data on an I/O module as a member of a named
Array of Words.
Module Identity
The following values will be stored in the Vendor ID, Product_Type,
Product_Code, Series_Rev, and Mod_Features arrays:
Parameter
Vendor ID
Product Type
Product Code
Series Rev
Module Catalog Number
Module Feature Code
Interrupts
Distance Rating
Input Data Type
Output Data Type
IF8u
58 (Spectrum Controls) [0×03A]
10 (Analog) [0×0A]
110 [0×06E]
50208 [0×C420] (First release revision
is 1.1)
2085sc-IF8u
0 [0×00]
Not Supported
8
16-bit Signed Integer
16-bit Collection of Bits
