Operating manual - English
POS. 8
POS. 4
POS. 7
POS. 3
POS. 6
POS. 5
POS. 15
POS. 14
POS. 13
POS. 9
POS. 12
POS. 11
POS. 2
POS. 1
POS. 10 libero
1 3 4 5
VISTA VALVOLE
PER CONNESIONE
2
CABLAGGIO
BROWN
BLACK
BLUE
SENSORE X
SENSOR X
SENSEUR X
DETECTOR X
SENSOR X
+
OUT
GND
Copyright Silca 2010
1
OUTPUT 2
RED
BLACK
KEY GUIDE PLATE ADVANCEMENT SOLENOID VALVE
2
AUXILIARY OUTPUT 1
RED
BLACK
KEY GUIDE PLATE BACK SOLENOID VALVE
3
RED
OUTPUT 4
BLACK
KEY EJECTOR GUIDE PLATE CYLINDER SOLENOID VALVE
4
OUTPUT 1
RED
BLACK
CLAMP OPEN/CLOSE SOLENOID VALVE
5
OUTPUT 3
RED
BLACK
GAUGE OPEN/CLOSE SOLENOID VALVE
BROWN F
KEY GUIDE PLATE LIMIT SWITCH F SENSOR
BLUE
BROWN C
KEY ADVANCEMENT LIMIT SWITCH C SENSOR
BLUE
BROWN E
KEY GUIDE PLATE LIMIT SWITCH E SENSOR
BLUE
BROWN B
INTERMEDIATE SENSOR B
BLUE
BROWN D
KEY GUIDE PLATE LIMIT SWITCH E SENSOR
BLUE
KEY BACK LIMIT SWITCH D SENSOR
UNOCODE 399 PLUS
4
3
2
1
Appendix - IX
