Silca Unocode 399 Plus Operating Manual page 55

Operating manual - English
C2
Figura 39
ATTENTION: if it is necessary
to work close to this area with
the machine turned on (e.g. to
regulate the X axis sensor) take
great care not to touch any
components on the machine's
electronic boards as it is
connected to 230 Volts.
Figura 40
Fig. 41
bottomview
X axis sensor
C3
Copyright S ilca 2010
Unocode 399 PLUS
Y axis sensor
C1
C2
C3
