Operating manual - English

1) Digit the card number (e.g.: 50):

2) Press ENTER:

Key Stop

Clamp to use

cut entry field

symbols allowed for data

Fig. 22

Fig. 23

(*) Adapter

on certain data cards provided by Silca the parameter "Adapt: B..." ind icates the type of accessory

needed to cut a key.

3) Digit the cuts.

In the cut entry field:

The dots shown represent possible cuts. The same card can be used for a number of keys with a dif-

ferent number of cuts.

If the key needs fewer cuts than the dots on display, just enter the partial combinat i on (from left to right).

in the case of double asymmetrical cuts, enter the cuts for both fields involved.

4) Press ENTER.

"Copy by data Card" procedure

Card No

Side 1

Side 1 x 2

Side 1 / Side 2

Symbols associated to cutting depths

Adapter* (if required)

Number of cuts per side for current key

Side 1: single cut

Side 1x2: double symmetrical cuts

Side 1 / Side 2: double asymmetrical cuts

Single cut

Double symmetrical cuts

Double asymmetrical cuts
