Silca Unocode 399 Plus Operating Manual page 65

Operating manual - English
• Appears when the cutting depth would not allow the cutter to move sideways.
• The depth exceeds the limits established for the clamp side in use.
• Cutting cannot be done for the type of stop set.
• Appears when the key blank measurement is altered and the depths exceed such measurement.
The cut depth is not
compatible with cutting
edge of the cutter.
See operating manual.
The cut depth exceeds
the safety limit of
the selected jaw side!
See operating manual.
The cutting process
is incompatible with
the STOP position !
See operating manual.
The depth values
can't be greater than
the Key Blank Dimension
See operating manual.
Copyright S ilca 2010
Unocode 399 PLUS
61
