Wi-Fi configuration
Security
Authentication
Encryption
9.6.10.2. Roaming
The Roaming dialog is used to define the following parameters:

Fig.9.26: Roaming dialog in the Roam Management menu

Roam
Signal Level (dBm):
Minimum Connection
Time (sec)
Logging Enable
Level
DLT-V72 Operating Instructions V2.50 Preliminary
The authentication process used, e.g. WPA2-PSK (Pre-Shared-
Key)
Display of the corresponding encryption process, e.g. (AES-CCMP,
TKIP)
This setting defines when the client is to be begin the roaming
process.
Possible values: -55 dBm to -80 dBm
Default value: -65 dBm (adjustable in 5 dBm increments)
This setting defines how long the client is to remain connected to
the current access point before roaming to the new access point
starts.
Possible values: 5 to 25 seconds
Default value: 10 seconds
This setting can be used to define that the activities of the driver are
recorded in a log. Two levels are available: Critical and All.
Critical: If the debug level is set to Critical, only the critical
messages from the driver will be recorded.
All: If the debug level is set to All, all messages from the driver will
be recorded.
The log file is saved in the C:\WlanLogs folder and a current
73 / 140
